Key Features

  • icon
    Engine (CC) 2365 CC
  • icon
    Clutch Type Dual
  • icon
    Gear Type
  • icon
    Drive Type 2WD

Model Overview

The John Deere 5036 D tractor offers a variety of features designed to meet the demands of farmers. It is equipped with a coolant cooling system and a dry-type dual-element air filter. The tractor has a single clutch, 8 forward plus 4 reverse gears, and utilizes Collarshift transmission technology. It operates at speeds ranging from 3.13 to 34.18 KMPH in forward motion and 4.10 to 14.84 KMPH in reverse. The tractor also features Oil Immersed Disc Brakes for efficient traction, a heavy hydraulic lifting capacity of 1600 KG with automatic depth and draft control linkage points, power steering for easy maneuvering, and a large 60-liter fuel-saving tank for extended working hours. Additionally, it is a 2WD tractor weighing 1760 KG, with a wheelbase of 1970 MM, ground clearance of 390 MM, and a turning radius of 2900 MM. It runs on 6.00x16 meter front tires and 12.4x28 meter rear tires. Furthermore, it is designed with advanced safety and convenience features such as a monitoring & tracking system, rollover protection system, adjustable front axle, and more. The tractor is also compatible with various accessories like a bumper, canopy, ballast weights, and tow hook, ensuring its versatility and utility on the field.

Product Overview

Eicher 333 Super Plus: A Comprehensive Overview When it comes to modern farming, having the right tractor can make all the difference. The Eicher 333 Super Plus is one of the standout options available today, blending power, efficiency, and advanced features to meet the demands of agricultural work. Let?s delve into what makes this tractor a reliable choice for farmers. Key Specifications The Eicher 333 Super Plus boasts a robust power output of 36 horsepower, which is powered by its SIMPSON water-cooled engine. With three cylinders and a cubic capacity of 2365 cc, this tractor delivers impressive performance across various agricultural tasks. Fuel efficiency is critical in farming, and the Eicher 333 Super Plus?s inline fuel injection pump ensures that every drop of fuel contributes to its effectiveness in the field. Versatile Transmission and Handling This model features a side-shift partial constant mesh transmission with 8 forward and 2 reverse speeds, providing versatility for a range of farming operations. Whether you need to navigate hilly terrains or perform intricate maneuvers, this tractor's transmission system offers the control needed to operate smoothly. The tractor also comes equipped with a mechanical steering system, with an option for power steering, enhancing the operator's comfort during long hours of usage. Additionally, the multi-disc oil-immersed brakes provide fabulous stopping power, ensuring safety when maneuvering through challenging landscapes. Lifting and Towing Capacity One of the standout features of the Eicher 333 Super Plus is its impressive lifting capacity. With a standard lifting capability of 1650 kgf at the lower links' horizontal position, this tractor is designed to handle heavy implements and equipment efficiently. It utilizes a three-point linkage system with draft, position, and response control, providing flexibility for various attachments and tools. Design and Build Quality The tractor's dimensions make it compact yet powerful. It measures 3475 mm in length, 1700 mm in width, and stands at 2205 mm tall, with a wheelbase of 1910 mm. Weighing in at 1930 kg, the Eicher 333 Super Plus is built for durability and stability on various terrains. The tire dimensions, featuring 6.0 x 16 inches at the front and 13.6 x 28 inches at the rear, further enhance its ability to perform in diverse agricultural settings. Comfort and Convenience The Eicher 333 Super Plus is designed to provide a comfortable working environment for operators. The 12 V, 75 Ah battery ensures reliable electrical performance, allowing for the use of various electrical implements without concern. The tractor also comes with a fuel tank capacity of 45 liters, allowing for extended operation without the frequent need for refueling. With accessories such as a tipping trailer kit, drawbar, and top link included, the Eicher 333 Super Plus is ready to handle multiple tasks right out of the gate.

Engine

  • Air Filter Oil bath type
  • Max Torque 133 Nm
  • No of Cylinder 3
  • Drive type 2 WD
  • Cooling System Water Cooled
  • PTO HP 31
  • Engine Rated RPM 2000RPM
  • Horse Power (HP) 36 HP
  • Engine Capacity 2365 CC
  • Engine Type DI Engine

Transmission

  • Reverse Speed (Min-Max) 10 kmph
  • Forward Speed (Min-Max) 28.65 kmph
  • Brake Type Oil Immersed Brakes
  • Clutch type Single / Dual clutch
  • Gear Box 8 Forward + 2 Reverse
  • Transmission Type Constant & sliding mesh

Specification

  • Fuel Tank Capacity 45 litre

Dimension and weight

  • Ground Clearance 360MM
  • Tractor width 1700 MM
  • Overall Length 3475 MM
  • Wheelbase 1910MM
  • Weight 1930 KG

Hydraulics

  • Linkage & Controls 3 Point Linkage
  • Lifting capacity (in kg) 1650 Kg

Assurance

  • Warranty 3000 Hour / 3 Year

Others

  • Electricals 12 V 75 Ah Battery
  • Accessories Tipping trailer kit, Bumper, Drawbar, Mobile charger, Top link, Water bottle holder
  • Turning radius with brake 3150 mm
  • Steering Type Mechanical /Integrated Power Steering(Optional)

Similar Tractors

Reviews

Eicher 333 Super Plus 2WD Tractor User Reviews

0 / 5
Based on 0 User Reviews
  • Fuel Consumption
    0
  • Design
    0
  • Maintenance Cost
    0
  • Multitasking
    0
  • star
  • star
  • star
  • star
  • star

Write a Review

Eicher 333 Super Plus 2WD Tractor

Rate Below Performance Parameter

Fuel Consumption
Maintenance Cost
Design
Multitasking

New Tractors in 31-40 HP

View All

Specifications Of Eicher 333 Super Plus 2WD Tractor

  • Air Filter Oil bath type
  • Max Torque 133 Nm
  • No of Cylinder 3
  • Drive type 2 WD
  • Cooling System Water Cooled
  • PTO HP 31
  • Engine Rated RPM 2000RPM
  • Horse Power (HP) 36 HP
  • Engine Capacity 2365 CC
  • Engine Type DI Engine

Specifications Of Eicher 333 Super Plus 2WD Tractor

  • Reverse Speed (Min-Max) 10 kmph
  • Forward Speed (Min-Max) 28.65 kmph
  • Brake Type Oil Immersed Brakes
  • Clutch type Single / Dual clutch
  • Gear Box 8 Forward + 2 Reverse
  • Transmission Type Constant & sliding mesh

Specifications Of Eicher 333 Super Plus 2WD Tractor

  • Fuel Tank Capacity 45 litre

Specifications Of Eicher 333 Super Plus 2WD Tractor

  • Ground Clearance 360MM
  • Tractor width 1700 MM
  • Overall Length 3475 MM
  • Wheelbase 1910MM
  • Weight 1930 KG

Specifications Of Eicher 333 Super Plus 2WD Tractor

  • Linkage & Controls 3 Point Linkage
  • Lifting capacity (in kg) 1650 Kg

Specifications Of Eicher 333 Super Plus 2WD Tractor

  • Warranty 3000 Hour / 3 Year

Specifications Of Eicher 333 Super Plus 2WD Tractor

  • Electricals 12 V 75 Ah Battery
  • Accessories Tipping trailer kit, Bumper, Drawbar, Mobile charger, Top link, Water bottle holder
  • Turning radius with brake 3150 mm
  • Steering Type Mechanical /Integrated Power Steering(Optional)
